Ideal for the PEG station that wants flexibility in configuring IP or SDI input/output options. Up to 12 configurable SDI ports and 5 playback/encode channels, RAID, redundant power.
I/O Configuration
Channels Up to 5 total Playback + Encodes (MAX 4 Playback, 4 Encodes)
HD-SDI Ports Up to 12
SDI Inputs All SDI ports not used for Playback available as auto-sensing, switchable inputs
IP Inputs Transport, RTMP, HLS via GigE. StreamThru™ IP Switching, optional Capture
HD/SD Simulcast Optional, requires 2 ports per Channel
Storage
OS/System SSD
Media 11.5TB, 8 Drive RAID 6 standard. Up to 32 TB for B2000-8 and B2000-12 models.
Media 5.5TB, RAID 5 for B2000-4 model.
Archive Optional Archive to NAS (FTP, CIFS) and Archive.org
Content
File Formats MPEG-2 Program, MPEG-2 Transport, DVDs, VOB, MP4, MOV, AVI
IP Streaming Formats MPEG-2 TS over UDP, RTP (Unicast, Multicast, SSM Multicast), RTMP, HLS
Video Codecs MPEG-2, H.264
Audio Codecs MPEG-1 Layer II, AC-3, AAC, MP3, LPCM
Closed Captions CEA-608/708
Video Bit Rates Up to 20 Mbps
Upload Protocols FTP, CIFS
Recording
Encode MPEG-2 Transport (MPEG-2 and H.264 SD/HD)
IP Capture Optional up to 4 Simultaneous
Playback
Video Resolutions
SD 480i29.97 NTSC & 576i25 PAL
720p50/59.94/60
1080p23.98/24/25/29.97/30
1080PsF23.98/24/25/29.97/30
1080i25/29.97/30
Automatic up/down-conversion
Audio Format 48 kHz, 16 bit
Audio Channels Stereo
Audio Processing Optional Real-time Audio Loudness Management (CALM Compliant)
VANCs CEA-608/708 Closed Captioning
Downstream Graphics
Bugs, Tickers, Snipes, Squeezebacks, Motion Logos, Emergency Tickers
Network Management
System Health Notifications SNMP, Email, REST API, and Web Browser UI.
Other Built-in Firewall & Routing Table, Remote Management, Station Timing Locked to NTP
High Availability
Watchdog Timer Solid State System Drive, RAID 6 Content Storage, Redundant Power Supplies
Physical
Power 100 – 240 VAC / 740 Watts
Dimensions 17.2″ x 3.5″ x 25.5″ (W x H x D)
Weight 35 lbs.
Form Factor 2RU Rackmount, 19” Standard
External Interfaces & Connections (Typically Used)
HD-SDI ports Up to 12
External Reference Blackburst in SD, 720p50, 720p59.94, 1080i50 and 1080i59.94 formats or Tri-Sync in any HD format.
Copper NICs Quad 10/100/1000 BT
Other NICs Option for Dual Fiber 10/100/1000 BT in lieu of 2x Copper.
Front Panel Power/Fail/Drive LEDs, Power/Reset Switch/ LCD Interface
Operating System
Linux, Standard Drivers
Application Software
User Interface Integrated, HTML Browser-based
Content Management Custom Metadata, Hierarchical Categories, Videos Previews with Virtual Trim Editing, Advanced Search, Bulk Actions, Optional Archiving Management
Scheduling Drag & Drop, Copy/Paste, Block Copy, Bulk Modify, Recur, Ripple, Import/Export
Continuity Auto fill Program Gaps with Playlists or Live sources
Graphics Built-in, WYSIWYG Editor, Multiple Simultaneous Overlays, Alpha Channel, Drop Shadow Text, Date & Metadata Variables
Reports As Run, First/Repeat Run, Missing Files
TV Listing Embeddable, Searchable Website Program Guide, Rovi X-List, XMLTV, Minerva, RSS
Traffic & Billing Optional CCMS
APIs REST, RSS, SNMP
User Management Roles, Emergency-only User, Preferences
Cloud Services
Optional Streaming & OTT with TelVue CloudCast™, Cloud Upload with TelVue Connect™
Note: Specifications are subject to change without notice.
|
